Robot Control Cable Custom
  • Robot Control Cable
  • Robot Control Cable

Robot Control Cable


Production Process
Rated Temperature:80℃/105℃
Rated Voltage:300/500V
Conductor Material: Multi-strand ultra-fine precision annealed oxygen-free copper wire, resistant to bending and breakage
Insulation Material: Special heat-resistant flame-retardant PVC insulation
Color: Black, White, Red, Yellow/Green (customizable per customer requirements)
Wrapping Material: Non-woven fabric wrapping to reduce core friction loss
Sheath Material:80℃ / 105℃ heat-resistant flame-retardant PVC sheath

Product Features
Ultra-high flexibility, corrosion resistance, oil resistance, wear resistance, resistance to repeated torsion and bending, UV resistance, anti-aging, long service life. Suitable for long-term continuous motion of robots, not prone to cracking or core breakage during long-term operation.

Application Scope
Industrial robotic arms, industrial robots, automated production lines, logistics conveying equipment, indoor cranes, packaging machinery, CNC machine tools, metallurgical industry, and other equipment requiring high-frequency reciprocating bending and moving power and signal connections.

Inquiry Now
  • Specifications & Technical Parameters

    Specification (mm²)

    Weight per 100m (KG)

    Outer Diameter

    Conductor Spec

    Core Color

    14X0.3MM

    12.8

    10.2

    38/0.10AS

    White coded 1-14 (cores twisted in pairs)

    16X0.3MM

    14.4

    10.8

    38/0.10AS

    White coded 1-16 (cores twisted in pairs)

    20X0.3MM

    16.95

    11.8

    38/0.10AS

    White coded 1-20 (cores twisted in pairs)

    24X0.3MM

    19.6

    12.8

    38/0.10AS

    White coded 1-24 (cores twisted in pairs)

    26X0.3MM

    21.6

    13.4

    38/0.10AS

    White coded 1-26 (cores twisted in pairs)

    30X0.3MM

    23.2

    14

    38/0.10AS

    White coded 1-30 (cores twisted in pairs)

    40X0.3MM

    28.7

    15.8

    38/0.10AS

    White coded 1-40 (cores twisted in pairs)

    14X0.5MM

    23.02

    13.2

    45/0.12AS

    White coded 1-14 (cores twisted in pairs)

    16X0.5MM

    24.74

    13.8

    45/0.12AS

    White coded 1-16 (cores twisted in pairs)

    20X0.5MM

    31.26

    15.4

    45/0.12AS

    White coded 1-20 (cores twisted in pairs)

    24X0.5MM

    37.5

    16.4

    45/0.12AS

    White coded 1-24 (cores twisted in pairs)

    26X0.5MM

    40.8

    17

    45/0.12AS

    White coded 1-26 (cores twisted in pairs)

    30X0.5MM

    48.3

    18.2

    45/0.12AS

    White coded 1-30 (cores twisted in pairs)

    40X0.2MM

    21.1

    13.6

    26/0.10AS

    White coded 1-40 (cores twisted in pairs)

    14X0.15MM

    9.1

    8.5

    20/0.10AS

    White coded 1-14 (cores twisted in pairs)

    16X0.15MM

    10

    9

    20/0.10AS

    White coded 1-16 (cores twisted in pairs)

    20X0.15MM

    11.8

    9.6

    20/0.10AS

    White coded 1-20 (cores twisted in pairs)

    24X0.15MM

    13.4

    10.4

    20/0.10AS

    White coded 1-24 (cores twisted in pairs)

    26X0.15MM

    13.8

    10.9

    20/0.10AS

    White coded 1-26 (cores twisted in pairs)

    30X0.15MM

    15.2

    11.2

    20/0.10AS

    White coded 1-30 (cores twisted in pairs)

    40X0.15MM

    18.2

    12.6

    20/0.10AS

    White coded 1-40 (cores twisted in pairs)

    14X0.2MM

    9.96

    8.9

    26/0.10AS

    White coded 1-14 (cores twisted in pairs)

    16X0.2MM

    10.9

    9.4

    26/0.10AS

    White coded 1-16 (cores twisted in pairs)

    20X0.2MM

    12.9

    10.2

    26/0.10AS

    White coded 1-20 (cores twisted in pairs)

    24X0.2MM

    14.6

    11

    26/0.10AS

    White coded 1-24 (cores twisted in pairs)

    26X0.2MM

    15.6

    11.5

    26/0.10AS

    White coded 1-26 (cores twisted in pairs)

    30X0.2MM

    16.9

    12

    26/0.10AS

    White coded 1-30 (cores twisted in pairs)

    40X0.15MM

    18.2

    12.6

    20/0.10AS

    White coded 1-40 (cores tw

About Us
Jiangsu Silver& Tin Thread Hi-temperature Wire and Cables Co., Ltd.
Jiangsu Silver& Tin Thread Hi-temperature Wire and Cables Co., Ltd., is China Robot Control Cable Manufacturer and Custom Robot Control Cable Suppliers, founded in Taizhou, Jiangsu Province in 1994, successfully registered the "Yuanzhi" trademark in 2002. The company specializes in the production and R&D of high-quality high-temperature cables. Its products primarily use Teflon, silicone rubber, flame-retardant polyethylene, and fire-resistant mica tape as insulation materials, and pure nickel, silver-plated, nickel-plated, tin-plated, and oxygen-free bare copper wire as conductors. The production process involves more than twenty steps, including wire bundling, cabling, stranding, extrusion, rubber extrusion, shielding, braiding, and coating. The company manufactures nearly a thousand specifications across eight major series, including cables for electrical equipment, control systems, signal transmission, computers, compensation, fire resistance, high and low temperature resistance, and high voltage resistance. Currently, it has the production capacity for conductor cross-sections up to 400mm², voltage up to 100kV, and temperature ratings from -65°C to +1200°C.
Our company's products are manufactured according to advanced international and national standards. Its garden-style production base has passed ISO9001 quality management system certification and is a "Comprehensive Quality Management Standard Compliance" enterprise certified by the Ministry of Agriculture. Our products have received CCC quality certification, UL safety certification (USA), and have been recognized as a "Famous Product of Township Enterprises in Jiangsu Province." They have passed the full sampling inspections conducted by the National Wire and Cable Testing Center, the Provincial Quality Supervision and Testing Center, and the Taizhou Municipal Bureau of Quality and Technical Supervision. Listed as a "Key Protected Product of Taizhou City," our products are used by large enterprises like Chunlan and high-tech fields such as the 95856th Unit of the Ministry of Aerospace Industry. Some products are exported. To further demonstrate our commitment to providing peace of mind to our customers, our products have been insured with the People's Insurance Company of China for many years. We are a company that "honors contracts and keeps promises."
Our company will continue to adhere to the quality policy of "meticulous quality control, unwavering commitment to customers, and technological advancement for enterprise development," with "customer satisfaction" as our guiding principle, and comprehensively expand the "Yuanzhi" business.
