TFJ Spiral Teflon Heating Wire


Production Process:
Product Standard: GJB773A/8A-2000
Rated Voltage: 600V
Temperature Range: -60°C to +200°C
Conductor Material: Nickel-Chromium
Wire Diameter Range: ø1.5-5.0mm
Resistance Range: 0.1-10000 Ω/m
Available Voltages: 5V, 12V, 24V, 36V, 48V, 110V, 220V, 230V, etc.

Product Features:
The spiral heating wire is a high-strength heating alloy wire wrapped around fiberglass and coated with Teflon. It offers stable heating performance and excellent bending properties.

Applications:
It is widely used in refrigerators, air conditioners, electric blankets, electric towel racks, footbaths, rice cookers, pet mats, electric warming clothing, car window heating, pipe heating, car seat cushions, jade mattresses, healthcare equipment, and freezer defrosting devices.

Inquiry Now
  • Specifications, structure and technical parameters:



    Structure

    Spiral diameter

    (mm)

    Sheath thickness

    (mm)

    Wire outer diameter

    (mm)

    Impedance

    (Ω/m)

    1 / 0.1

    0.8±0.1

    0.5

    1.8±0.2

    405±5%

    1 / 0.1

    0.8±0.1

    0.5

    1.8±0.2

    300±5%

    1 / 0.15

    0.9±0.1

    0.5

    1.9±0.2

    200±5%

    1 / 0.15

    0.9±0.1

    0.5

    1.9±0.2

    150±5%

    1 / 0.2

    1.0±0.1

    0.5

    2.0±0.2

    100±5%

    1 / 0.2

    1.0±0.1

    0.5

    2.0±0.2

    75±5%

    1 / 0.25

    1.1±0.1

    0.5

    2.1±0.2

    50±5%

    1 / 0.3

    1.2±0.1

    0.5

    2.2±0.2

    30±5%
