Battery Energy Storage Cable


Manufacturing Process:
Conductor: Tin-plated copper or bare copper conductor
Insulation: Specially formulated eco-friendly PVC, compliant with ROHS and REACH environmental standards
Outer Sheath: Special blend PVC, flame-retardant and environmentally friendly
Flame Retardancy: Meets UL VW-1 or CSA FT1 flame-retardant ratings
Peak Operating Voltage: 600V
Test Voltage: 4000V
Insulation Resistance: ≥20MΩ/KM (at 20°C)
Minimum Bending Radius:
Mobile Installation: Approx. 20×D (cable outer diameter)
Fixed Installation: Approx. 6×D (cable outer diameter)

Operating Temperature:
Mobile Installation: -10°C to +105°C
Fixed Installation: -30°C to +105°C


Inquiry Now
  • Model

    Number of Core Wires & Conductor Specifications

    Number of cores
    wires + conductor
    cross-sectional area

    Approximate
    Cable Outer
    Diameter (mm Max.)

    Approximate

    Cable Weight

    (kg/km)

    HRKCMCU-S-20AWG-2C

    2 * 20AWG

    2 * 0.5

    6.8

    68.6

    HRKCMCU-S-20AWG-3C

    3 * 20AWG

    3 * 0.5

    7.7

    83.1

    HRKCMCU-S-20AWG-4C

    4 * 20AWG

    4 * 0.5

    8.3

    99.7

    HRKCMCU-S-20AWG-5C

    5 * 20AWG

    5 * 0.5

    9.1

    116.8

    HRKCMCU-S-20AWG-6C

    6 * 20AWG

    6 * 0.5

    9.9

    135.2

    HRKCMCU-S-20AWG-7C

    7 * 20AWG

    7 * 0.5

    10.8

    146.6

    HRKCMCU-S-20AWG-8C

    8 * 20AWG

    8 * 0.5

    9.9

    167.5

    HRKCMCU-S-16AWG-3C

    3 * 16AWG

    3 * 1.5

    8.9

    122.5

    HRKCMCU-S-16AWG-4C

    4 * 16AWG

    4 * 1.5

    9.7

    150.2

    HRKCMCU-S-16AWG-5C

    5 * 16AWG

    5 * 1.5

    10.8

    183.2

    HRKCMCU-S-16AWG-6C

    6 * 16AWG

    6 * 1.5

    12.0

    217.0

    HRKCMCU-S-16AWG-7C

    7 * 16AWG

    7 * 1.5

    12.0

    238.3

    HRKCMCU-S-16AWG-8C

    8 * 16AWG

    8 * 1.5

    13.2

    285.7

    HRKCMCU-S-16AWG-9C

    9 * 16AWG

    9 * 1.5

    14.7

    327.5

    HRKCMCU-S-6AWG-3C

    3 * 6AWG

    3 * 16

    21.2

    744.3

    HRKCMCU-S-6AWG-4C

    4 * 6AWG

    4 * 16

    23.7

    963.2

    HRKCMCU-S-6AWG-5C

    5 * 6AWG

    5 * 16

    26.4

    1191.3

    HRKCMCU-S-6AWG-7C

    7 * 6AWG

    7 * 16

    29.3

    1600.8

    HRKCMCU-S-32AWG-3C

    3 * 32AWG

    3 * 35

    31.3

    1860.4

    HRKCMCU-S-32AWG-4C

    4 * 32AWG

    4 * 35

    35.0

    2360.8

    HRKCMCU-S-32AWG-5C

    5 * 32AWG

    5 * 35

    39.1

    2895.3

    HRKCMCU-S-32AWG-7C

    7 * 32AWG

    7 * 35

    43.3

    3874.2

    HRKCMCU-S-4/0AWG-3C

    3 * 4/0AWG

    3 * 120

    51.8

    4801.0

    HRKCMCU-S-4/0AWG-4C

    4 * 4/0AWG

    4 * 120

    57.9

    6290.4
